Nano PP Diffuser Plate

Nano PP Diffuser Plate

Product Parameters

Product Specification

Product Series
Nano PP Diffuser Plate
Model
PPKS
Thickness
0.6-3.0mm
Transmittance
40-65
Haze
89-93
Size Range
1300*2440mm(Customizable)

Specification

Property
Test Method
Unit
Test data
Tensile Strength ISO527
MPa
22.6
Tear Trength ISO527
MPa
20.1
Proportion ISO1183
g/cm3
 1.05
UV Resistance UVA
315-400nm
240H
UVA Treated
OK
High and low temperature test
GB/T
2423.1-2001
100 cycles
Qualified OK
(-30℃-+80℃)
Vicat
Softening
Temperature
ISO306

77.9
Heat Distortion Temp ISO75

93.8
Fire rating UL94
class
V2
Transmittance GB2410-80
%
61.2
Haze GB2410-80
%
91.7
RoHS Directive
2011/65/EU
(RoHs)

— —
Pass
SVHC Regulation (EC)
No 1907/2006 (REACH)

— —
Pass
GWEPT IEC
60695-2-11:2021


750






NOTE:
The above data are representative actual measurement data obtained through standard test methods, but not guaranteed values (the shipping standard values of key data are subject to internal tolerance or negotiated tolerance).



Product Utilization

The product uses nano-modification technology to change the molecular structure of PP and add nano-sized light diffuser agents, transforming point or line light source into soft and uniform surface light source. Nano PP material has good environmental performance, high resilience, strong yellowing resistance and flame retardant V2 rating.



References Download

Glow Wire Test.pdf

REACH.pdf


RoHS.pdf
